P040-0475-X2XX Specification

Mechanical:
· Pitch (Minimum):
· Working Force:

· Recommended travel:

· Operating temperature:

0.40mm
34.0g
0.70mm
-55°C to 120°C

Electrical:
· Typical Resistance (Avg):
· Current carrying capability:
· Bandwidth @-1dB IL (GSG):
· Loop inductance:
· Capacitance:

<70 mΩ
2.0 A
19.4 GHz
0.61 nH
0.36 pF

Material:
· Top plunger:
· Bottom plunger:
· Barrel:
· Spring:

Pd Alloy
BeCu, Gold plated
Phosphorous bronze, Gold plated
Music wire, Gold plated
